Cmill-A5 Milling Machine

5 Axis Linkage Milling
Zirdent Cmill-A5 Milling Machine

Zirdent Cmill-A5 Milling Machine

With max. spindle speed 60,000 rpm, A5 Pro combines utmost precision with maximum stability and every indication can be treated – crowns and bridges, inlays, onlays and more for dental laboratories on same day dentistry.

6000RPM Maximum spindle speed
5-axis Five-axis simultaneous
machining

Available Material

Versatile material compatibility for a wide range of dental CAD/CAM applications

ZIRCONIA
ZIRCONIA
PMMA
PMMA
WAX
WAX
PEEK
PEEK

Device Parameters

Engineered for precision, efficiency, and reliable multi-material dental milling

Axis
5 Axis
Maximum spindle speed
60000r/m
Input voltage
AC 220V
Operating power
1.75KW
Weight
83KG
External size
630mm*500mm*655mm
Cutting way
Dry +vacuum vleaning
Compressed air
0.5-0.8mpa Clean Air
Spindle cooling
Air cooling
Positioning accuracy
0.005mm
Tool numbers
5
Fixture
single disk: 98mm
Tool change
Automatic
Product type
coping/crown/bridge/inlay
Processing materials
Average processing time
wax/zirconia/pmma : disk thickness 10-25mm
model : 30-40min zirconia : 6-8min
